功用与详细资料/Brief Introduction：

该线由线条式挤出机螺杆洗瓶晒干集成机、服食液罐装轧盖机二台单机版版构成的，以分成清洁运作、常温、干燥无菌和罐装封口处三大运作区，全程可协同生产加工，也可单机版版运用。可完工淋水、多普勒彩超波清洁运作、冲水、冲气、晒干无菌、冷却后、罐装、理盖、戴盖、轧盖等步骤。The line is made up of two single machine, one straight-line screw bottle washing and drying machine and one oral liquid filling and capping machine. The line is divided into cleaning, drying, sterilization and filling sealing three workspace, all can joint production, also can use single. It can complete water spray, ultrasonic cleaning, water flushing, air flushing, drying sterilization, cooling, filling, cap arranging, capping, sealing, etc.

结构特征/Characteristic：

主要包括mri波洗涤及雾水交叠冲洗器、远红外温度消毒、双头灌装生产线与密封等科技。整线三级联动自己掌握。进行操作简略有利，变现了机电设备分离式化。Using ultrasonic cleaning and water washing alternately, far-infrared high-temperature sterilization, such as long filling and sealing technology. The automatic control of the whole line linkage. Simple and convenient operation, electromechanical integration is realized.

技能规格/ Technical Parameters：

生产能力technical parameters	80-150瓶/分80-150 bottles/min
选用型号规格 Cutting dimension	5-20ml
电  容  量Amount of electric capacity	65Kw(中仅正常情况办公36💃Kw)(including normal working 36 kw)
机器设备重量machine net weight	6800Kg
外形尺寸boundary dimension	9650×2360×1900mm（长×宽×高）(length x width x height)
