使用用途与百度百科/Brief Introduction：

滤油机组为10-20ml服用液液體分装生产方式的线中的主要装备。是由洗瓶、干燥合二为一机和分装封好合二为一机所成分，能自主顺利完成服用液瓶的洗瓶、干燥、分装和封好等行动，是服用液生产方式的生产商更佳的服务设施装备，基本具备GMP必须。It’s a major equipment in production line for oral filling, it main used in filling, capping placing and sealing of 10-20ml bottles. Tracking filling, cap automatically conveying by electromagnetic oscillator, automatic sealing , no bottle no filling. Filling and sealing integrated in one machine, advanced design, compact structure and completely comply with requirement of GMP

基本特征/Characteristic：

◆装量明确，避免出现渗漏。装罐可靠性强，精密程度高。High filling accuracy.◆调频魔宗可控硅调压，种植极限进程可控，可供选择择各不相同的种植极限进程。Frequency control, production speed is adjustable, you can choose a different production rate.◆拥有电气产品器件均适用德国前十强品脾。All electrical components are imported famous brands.◆自然表现筛选功效。Automatically countting function.◆设定采用了日本国三凌PLC，抗电磁干扰，岗位维持。Controlled by Mitsubishi PLC◆性能指标固定，维持养护简单方便。Stable performance, easy maintenance.◆组装机外表通常看上去进行SUS304不透钢材质的质作、与原辅料接触到方面进行316L不透钢材质的。组装机完全性按GMP必须设计的。Outer material is 304 stainless steel, and the material of filling part is 316L stainless steel. The machine is completely designed according to GMP requirements.

技術主要参数/technical parameters：

适合规格型号/Bottle size	10-20ml
生产销售力/Capacity	60-90瓶/分鐘/60-90bottles/min
风干平均温度/Dryer tempreture	100-300°
回收河水量/Water wastage	0.5m3/h
过滤水耗量/Purifying water consumption	0.3m3/h
装量的精密度/Filling precision	≤1%
电压/Voltage	380V/50Hz
电功率/Power	33KW
产生线总长/Dimension	3500×1500×1600mm
