主要用途与详细介绍/Brief Introduction：

全智能齿轮泵式膏体酱装罐机是我们集团公司适合领域标准开放的新成品。设备分为SUS304不锈钢装饰管吗齿轮泵式计量检定泵执行命令装罐，且集智能上盖、智能旋盖、机电设备电力电气为分离式，成本实用型，土地征用户型小，常见采用于生物制药、面制品、药剂、化工公司、化妆造型品等制造行业的液态物质包裝，契合GMP规定符合要求。Automatic plunger paste paste filling machine is my company to meet the market demand, introduction of foreign advanced technology to develop new products. This machine adopts SUS304 stainless steel plunger metering pump filling, cover and set for automatic, automatic screw cap, integration of the mechanical and electrical, economical and practical, cover an area of an area small, widely used in pharmaceutical, food, pesticides, chemical industry, cosmetics and other industries of liquid packaging, full compliance with GMP requirements.

优势特点/characteristic：

◆采取齿轮泵式压力容器检验泵履行罐装，应用各式各样黏稠度药液，定位精性好；泵的框架采取快接式拆迁培训机构，更加方便洗涤、酒精消毒。Adopt plunger type metering pump filling, used various viscosity liquid, high precision; The structure of pump adopts fast disassembly institutions, easy cleaning and disinfection◆注塞泵式测量泵活塞件环木头质地依照行业中及液滴含量的各不相同用于硅硅胶，四氟丁二烯或其它的木头质地，独特的场所用于工业陶瓷木头质地。Plunger metering pump piston ring material according to the industry and different adopt silicon rubber, liquid ingredients tetrafluoroethylene or other material, special occasions with ceramic material◆PLC操作系统性，直流变频变速，一键化能力高。PLC control system, frequency control of motor speed, a high degree of automation◆缺瓶不灌装线，自然数值特点。Lack of bottle filling, automatic counting function◆装量调准以便于，可以次调准大部分的计量校准泵的充填量，也可真对各级的计量校准泵开始微幅调准；操作流程简便方法，调准怏速。The load adjustment is convenient, can be a filling quantity of all pumps also can be slightly adjusted according to various metering pump; Simple operation, rapid adjustment◆分装线针头存在防渗漏装置设备，充填时突入瓶底分装线，放缓上升的，防范裂痕。Filling needles a drip-proof device, filling into the bottom of the bottle filling, slowly rising and prevent bubbles.◆整个设备可适宜不一样的年纪的水瓶座，修正操作简单，可在瞬時间内成功完成。The machine is suitable for various specifications of bottles, easy adjustment, it can be finished in a short period of time◆空机按GMP要设汁。The machine designed according to the requirements of GMP

技能数据/technic parameter：

适宜小瓶规格尺寸Size of bottles	20-1000ml（可根据规定要求为您加工定制）20-1000꧑ - ml (according t💃o your need）
用于矿泉水瓶网套直径Apply the bottle diameter	¢20-¢150mm
用于盖子型号规格Apply the lid specifications	¢20-¢70mm
产量技能 production capacity	四头灌装生产线：1000-2500瓶/个小时 Four filling head: 1000-2500 bottles per hour 八头灌装线：2500-4000瓶/个钟头 Eight head filling: 2500-4000 bottles per hour 12头灌装设备：4000-6000瓶/小时左右 12 head filling: 4000-6000 bottles per hour
装量粗差The load error	±1%
旋盖合格证书率Screw cover percent of pass	≥99%
电power supply	380V，50HZ
电机功率power	3.0KW
源gas sources	0.4-0.75MPA
极限速度调控speed control	交流变频变频调速variable speed
