功能与简单介绍/Brief Introduction：

机器是我们企业在消除海外高端技能的基础性上生产制造的，使用噴霧剂包装的专用工具主设备。用途各式类型金属材质圆型、异型瓶，各式类型年纪喷头型号的包装旋（轧）盖。不锈钢材质活塞环泵一定量包装、气动平衡上盖、伸降式旋盖。具备有包装检定正确、旋盖平静、基本操作很简单等优势之处。发生目前中国技术型实力。非常广泛应使用药业、日化用品等行业内。The machine is special purpose for filling spray. It’s fit for all kinds of bottles of materials and shapes ,This machine is available for series of round and flat bottles. It adopts stainless piston measuring pump for filling, pneumatic capping, and rising-and-falling screwing. The machine enjoys advantages of accurate measurement, stable screwing and easy operation,widely used in pharmaceuticals and cosmetic industry

结构特征/Characteristic：

◆任何电子产品部件均按照着时尚企业牌。超声波焊接机操作的直观性简便，无瓶不包装，记量*，无瓶不上盖。All elements is well know brand. Direct viewing operation, no bottle no filling, measuring accurate, no bottle no capping.◆上盖位置定位安全装置，以确保喷咀塑胶管太短或弯折变形时也是可以正确进到瓶口。Cap adding device, ensure pipe of cap into mouth of bottle easy even it’s long or crooked。◆ 仍然是以GMP标准打造。The whole machine is designed according to the requirements of GMP.

高技术指标/Technical Parameters：

适合年纪Filling Volume	5-500ml
生孩子特性Productivity	30-50瓶/分   60-100瓶/分 30-50bottles/min  60-100bottles/min
装罐精确Filling Precision	≤±1%
电源适配器Plugging ratio	380V/50Hz
上盖率 Air Supply	≥98%
供气Power Supply	1.5M3/钟头 0.4-0.7Mpa
额定功率Power	1.5 kw
器机重量 Weight	500 kg
样貌尺寸图Dimension	2000*1000*1500mm
